Heavy-duty timber-to-timber connector screws with a large flat wafer head, TXD star drive, and bronze Nano KTCO coating tested to 2000 hours salt spray resistance. Sharp 25-degree point, dual cutter slots, and a rollet shaft for fast, clean fixing without splitting.
Size
Price
QTY
6.0 x 60mm
£3.59£4.31
6.0 x 80mm
£4.82£5.78
6.0 x 100mm
£6.06£7.27
6.0 x 120mm
£7.30£8.76
6.0 x 140mm
£8.54£10.25
6.0 x 160mm
£12.25£14.70
6.0 x 180mm
£14.72£17.66
6.0 x 200mm
£19.67£23.60
6.0 x 220mm
£22.15£26.58
8.0 x 80mm
£6.06£7.27
8.0 x 100mm
£8.04£9.65
8.0 x 280mm
£35.27£42.32
8.0 x 320mm
£40.22£48.26
8.0 x 360mm
£42.69£51.23
8.0 x 400mm
£48.88£58.66
8.0 x 120mm
£9.28£11.14
8.0 x 140mm
£11.01£13.21
8.0 x 150mm
£11.76£14.11
8.0 x 160mm
£12.99£15.59
8.0 x 170mm
£16.09£19.31
8.0 x 200mm
£19.18£23.02
8.0 x 240mm
£27.84£33.41
8.0 x 280mm
£35.27£42.32
Reisser timber connector screws are built for structural timber work where a standard fixing just won’t cut it. The wafer head design gives you greater pull-through resistance and better clamping force than a countersunk or hex head screw, which makes a real difference when you’re pulling warped or bowed timber into line. The flat, low-profile head also sits flush and looks clean where fixings are on show.
The sharp 25-degree point gets the screw started fast without pre-drilling, and two CUTTER slots near the tip let you fix close to the edge of timber without the risk of splitting. That’s a detail worth having when you’re working near board ends or tight to a joist edge.
What Sets Reisser Timber Connector Screws Apart
A ‘rollet’ feature on the shaft reduces drag and torsion as the screw drives home. In practice, that means less effort, less heat build-up, and a faster overall fixing. The TXD star drive is designed to maximise torque transfer while keeping cam-out to a minimum, so you’re less likely to strip the drive when you’re pushing hard on a long fixing into dense timber.
The steel is specially hardened to give maximum tensile and torsional strength, while still allowing a minimum 30-degree bending angle before failure. That flexibility matters in structural applications where loadings aren’t always perfectly aligned.
Nano KTCO Coating
The bronze Nano KTCO coating is tested to a minimum of 2000 hours salt spray resistance and is Cr-6 free. It resists peeling in timber, which matters more than people realise. A coating that stays intact keeps corrosion protection working across the full life of the fixing. Available in a wide range of lengths and diameters across 6mm and 8mm shank sizes to suit most structural and heavy-duty timber applications.
Pro Tip: When driving 8mm diameter fixings into hardwood or engineered timber, a light application of wax or soap to the screw thread will reduce driving torque noticeably and protect your bit from premature wear.
Reisser timber connector screws are used across structural framing, decking subframes, joist hangers, post and beam connections, and general heavy-duty timber construction. They're well suited to connecting thick section softwood and engineered timber where clamping force and pull-through resistance matter. Carpenters, groundworkers, and structural joiners use them on house builds, timber frame projects, garden structures, and commercial fit-out where timber loads need a dependable fixing.
Best For
Structural timber-to-timber connections
Decking subframes and joist fixing
Post and beam joinery
Heavy-duty framing and timber construction
Fixing close to board edges without splitting
Compatible With
Softwood and hardwood structural timber
Engineered timber and LVL
TXD star drive bits
6mm shank sizes: 60mm to 220mm lengths
8mm shank sizes: 80mm to 400mm lengths
Key Specifications
Nano KTCO bronze coating
2000hr minimum salt spray resistance
Cr-6 free corrosion protection
25-degree sharp point for fast start
Dual CUTTER slots reduce splitting risk
Rollet shaft reduces driving drag
Minimum 30-degree bending angle
TXD star drive for maximum torque transfer
Not suitable for: Not suitable for fixing into masonry, concrete, or metal sections. The wafer head profile is not ideal where a fully countersunk flush finish is required in sheet materials.
No pre-drilling is required in most softwood applications. For hardwood or dense engineered timber, especially with the 8mm diameter screws, a pilot hole will reduce the risk of splitting and make driving easier. Always use the correct TXD star drive bit to get full torque transfer and avoid cam-out on longer fixings.
Drive at a controlled speed. Running too fast generates heat and can cause the coating to pick up on the timber surface around the head. The rollet shaft does the work on thread engagement, so you don't need to force it. The screw will seat cleanly with the head flat against the timber surface when fully driven.
Select the correct length and diameter for the timber section being fixed, ensuring the screw reaches adequate depth into the receiving member
For hardwood or dense engineered timber, drill a pilot hole slightly smaller than the screw shank to prevent splitting and reduce driving torque
Fit a TXD star drive bit to your drill or impact driver
Position the screw at 90 degrees to the timber face and apply light pressure to seat the sharp point before driving
Drive at a controlled speed, allowing the rollet shaft to pull the screw through without forcing
Stop when the wafer head sits flush and flat against the timber surface, ensuring even clamping across the full head area
Do these screws need pre-drilling in softwood?
No, the sharp 25-degree point and dual CUTTER slots mean they can be driven directly into most softwood without a pilot hole, including close to edges. For hardwood or dense engineered timber, a pilot hole is recommended to reduce splitting risk and protect your drive bit.
Are these screws suitable for outdoor use?
Yes. The Nano KTCO bronze coating is tested to a minimum of 2000 hours salt spray resistance and is Cr-6 free, making it a solid choice for exposed and external timber applications including decking subframes, garden structures, and structural connections in wet or humid conditions.
Reisser wafer head timber connector screws are manufactured from specially hardened steel that combines high tensile and torsional strength with a minimum 30-degree bending angle before failure. The bronze Nano KTCO coating provides corrosion protection tested to a minimum of 2000 hours salt spray resistance in accordance with standard testing protocols. The coating is Cr-6 free and formulated to resist peel-off in direct contact with timber, maintaining protection across the full service life of the fixing.
6.0 x 100mm, 6.0 x 120mm, 6.0 x 180mm, 6.0 x 200mm, 6.0 x 220mm, 6.0 x 60mm, 6.0 x 80mm, 8.0 x 100mm, 8.0 x 120mm, 8.0 x 150mm, 8.0 x 200mm, 8.0 x 240mm, 8.0 x 280mm, 8.0 x 360mm, 8.0 x 80mm, 6.0 x 140mm, 6.0 x 160mm, 8.0 x 140mm, 8.0 x 160mm, 8.0 x 170mm, 8.0 x 320mm, 8.0 x 400mm
Box Quantity
25
